Andruino App is a wired and wireless home sensors for iPhone

Intro

Andruino App

Buying a low cost Arduino open-source electronics prototyping platform, you can control all what you want in your home simply connecting Arduino board to ethernet plug or a Wi-Fi network.

You can connect whatever analog/digital sensors on hardware board and Andruino App communicates with them, displaying in real time the room temperatures (C°/K°), the lights/plugs power consumption (Watt), the kitchen humidity (%), opened doors, and any other informations that comes from your home.
You can switch ON/OFF relays, control PWM outputs, and create pulses.

MAPS

Sensors and Controls on a real map of your home

Andruino is the first App in which you can drag and drop sensors and controls over a real map of your home.
Maps can be uploaded from camera your roll and then adjusted in the App.
Sensor and control icons can also be resized and adjusted.

Configuration

Andruino is 100% customizable

The App will work on wired and wireless local networks as well as 3G/4G wide area networks.
It can also work without an internet connection in direct mode on your local network.
Sensor configuration can be customized for unit of measure, mathematical formula and number of decimals according to sensor requirements.

Each sensor and relay is fully configurable (both analog/digital/PWM) and there is no limit to the number of sensors or controls that can be used.

Timers can be configured to switch on at a desired time and with a duration up to 18 hours. Time is synchronized every time the AndruinoApp is connected and the clock is maintained using the Arduino internal oscillator (no RTC is required).
You also have the option to manage a sensors digital output state. For example, you can invert output PIN logic so that a sensor works with inverted logic such as 0 -> active, 1-> not active.



MAPS

Ambients

With multi board management you can control any number of Arduinos. Imagine having 10 or more Wifi controllers displaying information on   a unique map of your home.

This gives you the ability to view multiple environments  with either single or multiple controllers.



datalogger

Datalogger and Graphs

Each sensor’s data can be plotted on a graph with Average/Max/Min values are calculated and displayed. This allows you to see  trends in sensor data. For example you can see a graphic display of temperature for the last two days, weeks or months using the datalogger function.

The datalogger stores data using a CSV file format and can be easily exported.

Alarms

Alarms/Events and Push notifications

For each sensor you can set low and an high limit triggering  which can be used to push notifications and to provide output activations.
Andruino can send real time push notifications when an event is triggered and/or a limit is reached.
You can continue to control your sensors even when AndruinoApp is closed. A notification with sensor data can be sent to your iPhone.


A special push notification can be enable when the board is powered up or down. This is used to monitor if the board is powered off for a reason such as a power loss.
You can also configure triggers on sensor outputs to control additional devices. This could be used for example to turn on a fan when a temperature reaches a defined point.



Configurations

Predefined configurations

The App and sketch come with predefined sensor configurations. Some examples include DHT22, Dallas DS18B20, TMP35/36/37, brightness, current sensors, REED switches, etc. All of these have custom templates with detailed information to simplify the electrical connections and configuration.

board

Board list

Arduino board view: this allows you to see all the connected boards with there online and pairing status.
Global sensor list: With this you can easily see all the sensors configured on your user account.



Andruino Winner during Arduino-Day 2019

Andruino Project has been selected by a panel of experts as the winner of the HOME AUTOMATION category in the Arduino Day Community Challenge

features

What You Get

Temperature and humidity

Temperature, humidity and various type of connected sensors can be read in real time and can be stored on a datalogger.

Relay

The output PIN state can be modified simply switching an icon on the map. The state of the PIN will change only when the App will receive the feedback from the board.

 Buttons

An output PIN can be configured as “pulse” if you need to drive bistable relays or open electric locks.

Icons

Each sensor can have a different icons, switches, lamps, etc.

Power consumption

Monitor the power consumption of your home and store it on a graph.

Wi-Fi and 3/4G

Works with Wi-Fi and 3/4G connections. The boards can be also placed in different Wi-Fi zones.

Timers

Each output PIN can be managed by a timer. You can switch them on or off at a specific time and for a specific duration.

Triggers

You can setup a trigger based on sensor readings and have it control another output.

Notifications

Each board can send a push notification such as when a temperature limit is reached or an alarm has been triggered.
